Restart your Inverter

Inverter | The Heart of your System

Your inverter is considered to be the most important aspect of your solar system. It controls every part of the power generation within the system and provides all the information you see in your monitoring portal.

Because your inverter constantly monitors the quality of the electricity from the grid, it will disconnect from the grid if there are any discrepancies in voltage or frequency. This is a safety precaution to stop your inverter from being overloaded.

Your inverter will also de-activate at night and once the sun rises and is strong enough, the inverter will automatically boot itself back up – it will also complete a safety test before feeding back to the grid with electricity. It is normal for inverters to turn off when no power is being produced (i.e. at night).

How to Restart your Inverter

Fronius
SolarEdge
Huawei
Sungrow
SMA

Step 1. Locate the AC “Main Switch Inverter Supply” which should be located in your switchboard.

Step 2. Turn off the “PV Array DC Isolator” which should be located next to your Fronius inverter.

Step 3. Wait for system to do a full shut down, roughly 30 seconds.

Step 4. Turn on “PV Array DC Isolator”.

Step 5. Turn on DC “Main Switch Inverter Supply”.

Your system will take a few minutes to completely reboot. Warning: Do not open plug and socket connection or PV array DC isolator under load.

Step 1. Turn off your AC isolator. This is the Solar Supply Main Switch located on your Switchboard.

Step 2. Turn off your system’s DC isolator. You’ll find this switch on the underside of your Fronius inverter.

Step 3. Please wait roughly 30 seconds for your system to completely power down.

Step 4. Please turn back on your DC isolator, followed by your AC isolator.

Step 5. Wait roughly 3-5 minutes for your system to completely reboot.

Step 1. Turn off your AC isolator. This is the Solar Supply Main Switch located on your Switchboard.

Step 2. Turn off your system’s DC isolator. You’ll find this switch on the underside on the left of your Huawei inverter.

Step 3. Please wait roughly 30 seconds for your system to completely power down.

Step 4. Please turn back on your DC isolator, followed by your AC isolator.

Step 5. Wait roughly 3-5 minutes for your system to completely reboot.

For a hard reset using your LCD screen, please follow these instructions from Huawei here.

Step 1. Turn off your AC isolator. This is the Solar Supply Main Switch located on your Switchboard.

Step 2. Turn off your system’s DC isolator. You’ll find this switch on the underside of your Sungrow inverter.

Step 3. Please wait roughly 30 seconds for your system to completely power down.

Step 4. Please turn back on your DC isolator, followed by your AC isolator.

Step 5. Wait roughly 3-5 minutes for your system to completely reboot.

Step 1. Turn off your AC isolator. This is the Solar Supply Main Switch located on your Switchboard.

Step 2. Turn off your system’s DC isolator. You’ll find this switch on the underside of your SMA inverter.

Step 3. Please wait roughly 30 seconds for your system to completely power down.

Step 4. Please turn back on your DC isolator, followed by your AC isolator.

Step 5. Wait roughly 3-5 minutes for your system to completely reboot.

If you are still having issues with your inverter after a successful restart, please call our office on 9300 9324 or email info@solairelifestyle.com.au.
